| Specification | 65" Interactive Display WAF Android OS (Option 1) | 75" Interactive Display WAF Android OS (Option 2) | 86" Interactive Display WAF Android OS (Option 3) |
|---|---|---|---|
| Display | |||
| Diagonal Size | 65" | 75" | 86" |
| Panel Type | IPS | IPS | IPS |
| Resolution | 3,840 x 2,160 | 3,840 x 2,160 | 3,840 x 2,160 |
| Pixel Pitch (HxV) | 372(H)x372(V) | 429.6(H)x429.6(V) | 493.5 x 493.5 mm |
| Brightness (Typ) | 400nit | 400nit | 400nit |
| Contrast Ratio | 1,200:1 | 1,200:1 | 1,200:1 |
| Viewing Angle (H/V) | 178/178 | 178/178 | 178/178 |
| Response Time | 8ms | 8ms | 8ms |
| Colour Gamut | 72% | 72% | 72% |
| Glass Haze | 25% | 25% | 25% |
| H-Scanning Frequency | 135 kHz | 135 kHz | 135 kHz |
| Maximum Pixel Frequency | 78MHz | 78MHz | 78MHz |
| V-Scanning Frequency | 60Hz | 60Hz | 60Hz |
| Operation Time Support | 12/7 | 12/7 | 12/7 |
| Connectivity | |||
| HDMI In | 2 | 2 | 2 |
| Version of HDMI | 2.1 | 2.1 | 2.1 |
| Version of HDCP | 2.1 | 2.1 | 2.1 |
| USB | 4 | 4 | 4 |
| Audio In | Stereo Mini Jack | Stereo Mini Jack | Stereo Mini Jack |
| Audio Out | Stereo Mini Jack | Stereo Mini Jack | Stereo Mini Jack |
| Video Out | Yes | Yes | Yes |
| RS232 In | Yes | Yes | Yes |
| RJ45 In | Yes | Yes | Yes |
| WiFi | Wi-Fi 5: 802.11ac | Wi-Fi 5: 802.11ac | Wi-Fi 5: 802.11ac |
| Bluetooth | Yes | Yes | Yes |
| Power | |||
| Power Supply | AC100-240V 50/60Hz | AC100-240V 50/60Hz | AC100-240V 50/60Hz |
| Power Consumption (On Mode) | 409 W | 450 W | 493 W |
| Power Consumption (Sleep Mode) | 0.5 W | 0.5 W | 0.5 W |
| Dimension | |||
| Set Dimension (WxHxD) | 1482.1 x 897.5 x 87.7 mm | 1716.5 x 1031.9 x 87.7 mm | 1961.8 x 1170 x 87.7 mm |
| Package Dimension (WxHxD) | 1640 x 1010 x 185 mm | 1860 x 1125 x 185 mm | 2095 x 1265 x 185 mm |
| Weight | |||
| Set Weight | 36.2 kg | 49.2 kg | 62.5 kg |
| Package Weight | 44.5 kg | 58.8 kg | 74.1 kg |
| Operation Conditions | |||
| Temperature | 0℃~40℃ | 0℃~40℃ | 0 ~ +40℃ |
| Humidity | 10 ~ 80%, non-condensing | 10 ~ 80%, non-condensing | 10 ~ 80%, non-condensing |
| Mechanical Specification | |||
| VESA Mount | 600 x 400 mm | 800 x 400 mm | 800 x 600 mm |
| Bezel Width | 14.0mm | 17.2mm | 17.2mm |
| Bezel Color | Black | Black | Black |
| Frame Material | Aluminium | Aluminium | Aluminium |
| Optional Feature | |||
| Touch | Yes | Yes | Yes |
| SoC | |||
| OS Version | Android-14 | Android-14 | Android-14 |
| Flash Memory Size | 64GB | 64GB | 64GB |
| Touch | |||
| Touch Technology | IR | IR | IR |
| Certification and Compliance | |||
| EMC | FCC CFR Title 47, Part 15, Subpart B/EN55032:2015+A11:2020 | FCC CFR Title 47, Part 15, Subpart B/EN55032:2015+A11:2020 | FCC CFR Title 47, Part 15, Subpart B/EN55032:2015+A11:2020 |
| Safety | IEC62368-1/UL62368-1/IEC60950-1 / IS13252 | IEC62368-1/UL62368-1/IEC60950-1 / IS13252 | IEC62368-1 / UL62368-1 / IEC60950-1 / IS13252 |
