• 4MP Super-High Definition: The camera comes with 4MP–more than enough pixels to pick up some of the more discrete details.
• 24h Full-Color: Experience clear, vibrant 24-hour monitoring, even in total darkness.
• 4G Mobile Networking: Enjoy hassle-free installation and simple monitoring in places where the internet is not available.
• 360° Monitoring: Cover every corner and eliminate blind spots.
• Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
• Smart Detection: Actively detects abnormal events like area intrusion and line-crossing, sending notifications to you instantly.
• Automatic Tracking: Automatically tracks persons or vehicles of interest and provides seamless and longer video.
• Active Defense: Warn potential intruders instantly with sound and light when abnormal events.
• Two-Way Audio: With voice intercom support, carry two-way conversations while watching your feed from anywhere.
• H.265+: Compresses the video size without sacrificing video quality, easing the network load and saving disk space.
• IP66 Waterproof: Reliable IP66 for stable outdoor performance.
• Remote Management: Take full control over your security anytime and anywhere on the VIGI app or PC client.
• Onboard Storage: Support on-board storage up to 256 GB (SD card slot).*

High Definition Full-Color 4G Mobile Networking
360° Monitoring Powerful Pan Tilt
Human & Vehicle Classification Automatic Tracking Smart Detection
Active Defense Two-Way Audio IP66 Smart Video Coding

Clarity and Colors, All in One
Experience clear, vibrant 24-hour monitoring, even in total darkness, with the VIGI Full-Color camera. Its 4MP resolution, large-aperture lens, high-sensitivity sensor, and supplemental lights deliver comprehensive, colorful surveillance.

Network Anywhere You Need It
No need to connect network cables. Just insert a Nano-SIM card, then your camera is ready to connect to a 4G LTE network. Enjoy hassle-free installation and simple monitoring in places where the internet is not available, such as farms, forests, and construction sites.

Powerful Pan Tilt
Cover every corner flexibly with VIGI’s Pan Tilt camera. Customized patrol routes provide more intelligent and quick options to monitor key areas (up to 8 points for each route), reducing manual costs for adjusting pan & tilt angles repeatedly.

• Tilt Range: -10-110°
• Pan Range: 0-345°
• 360° Monitoring
• 300 Presets
• 8 Patrol Routes
• 44°/s Preset Tilt Speed
• 44°/s Preset Pan Speed

Human & Vehicle Classification
Integrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.

Automatic Tracking
Automatically tracks persons or vehicles of interest and provides seamless and longer video. This way, you will better understand what's happening and take action without wasting time on irrelevant footage.

Smart Detection for Efficient Monitoring
By setting the detection rules in advance, VIGI AI-powered cameras can accurately capture various abnormal events. This will greatly reduce false alarms and cover your specified monitoring needs in different scenarios.

• Intrusion Detection
• Line-Crossing Detection
• Region Entering Detection
• Region Exiting Detection
• Abandoned Object Detection
• Object Removal Detection
• Set customized activity zones around key areas for more focused monitoring.

Active Defense
Warn potential intruders off instantly with sound and light to proactively protect your property, even while away from the scene.

Two-Way Audio
With voice intercom support, carry two-way conversations while watching your feed from anywhere.

Smart Video Coding Technology
Smart Video Coding by H.265+
Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.

IP66 Weatherproof
Reliable IP66 enables stable outdoor performance.

Flexible Storage
Local storage is available for each method, and an SD card slot (up to 256 GB) offers onboard storage.

Remote Management
Take full control over your security anytime and anywhere on the VIGI app or client.

Live Views and Real-Time Alerts
Easily check your business security via 24/7 live views. Get notifications as soon as the cameras detect something abnormal.

Easy & Smart Playback
Customized Monitoring Patterns
Four-Way Management
One system. Full security.
Run your business with peace of mind.
The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.

Camera

Image Sensor

• 1/3.06” Progressive Scan CMOS
• Shutter Speed: 1/3 to 1/10000 s
• Slow Shutter: Yes
• Minimum Illumination: 0.005 Lux; 0 Lux with IR/White Light
• Day/Night Mechanism: IR Cut Filter
• Day/Night Switch: Unified/ Scheduled/ Auto

Lens

• Type: Fixed Focal Lens
• Focal Length: 4 mm
• Aperture: F1.6
• FOV:
  • Horizontal FOV: 80°
  • Vertical FOV: 43°
  • Diagonal FOV: 94°
• Lens Mount: M12*0.5
• DORI Distance:
  • Detect: 80 m (262 ft)
  • Observe: 33 m (109 ft)
  • Recognize: 16 m (52 ft)
  • Identify: 8 m (26 ft)

PTZ

• Pan/tilt Range:
  • Pan: 0° to 348°
  • Tilt: 0° to 120°
• Pan/tilt Speed:
  • Pan Speed: Configurable from 8° to 44°/s; Preset Speed: 44°/s
  • Tilt Speed: Configurable from 8° to 44°/s, Preset Speed 44°/s
• Manual Control Speed: Configurable from 8° to 35°/s
• Presets: 300
• Patrol Scan: 8 patrols, up to 8 presets for each patrol
• Power-off Memory: Yes; Auto restore to previous PT and lens status after power failure
• Park Action: Yes; Preset; Patrol Scan
• 3D Positioning: Yes

Angle Adjustment (Manual)

• Range:
  • Pan: 0° to 348°
  • Tilt: 0° to 120°

Illuminator

• IR LED:
  • Quantity: 2
  • Range: 30m
  • Wavelength: 850nm
• White LED:
  • Quantity: 2
  • Range: 30m
• Illuminator On/Off Control: Auto/Scheduled/Always on/Always off

Video

• Max. Resolution: 2560 X 1440
• Main Stream:
  • Frame Rate:
    • 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
    • 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
  • Resolution: 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720
• Sub-Stream:
  • Frame Rate:
    • 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
    • 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
  • Resolution: 640x480, 352x288, 320x240
• Bit Rate Control: CBR, VBR
• Video Compression:
  • Main Stream: H.265+/H.265/H.264+/H.264
  • Sub-Stream: H.265/H.264
• H.264 Type: Main Profile/High Profile
• H.264+: Main Stream Supported
• H.265 Type: Main Profile
• H.265+: Main Stream Supported
• Video Bit Rate:
  • Main Stream: 256 Kbps to 3 Mbps
  • Sub-Stream: 64 Kbps to 512 Kbps


• Image Settings:
  • Mirror
  • Brightness
  • Contrast
  • Saturation
  • Sharpness
  • Exposure, WDR
  • White Balance
  • Prevent Overexposure to Infrared Light
  • HLC Adjustable by Client Software
  • Rotation (90°/270°)
• Image Enhancement: BLC/3D DNR/HLC/SmartIR
• Wide Dynamic Range: DWDR
• SNR: ≥ 52 dB
• Image Parameters Switch: Yes
• Privacy Mask: Up to 4 Masks
• ROI: 1 Region
• OSD Setting: Yes

Audio

• Audio Communication: Two-Way Audio
• Audio Input: Yes
• Audio Output: Yes
• Audio Compression: Yes
• Audio Sampling Rate: 8KHz
• Environment Noise Filtering: Yes
• Audio Bit Rate: 64 Kbps(G.711 alaw)

Network

• Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
• ONVIF: Yes
• API: ONVIF
• Simultaneous Live View: 2 Main Streams & 2 Sub-Streams
• Client: VIGI App, VIGI Security Manager, Web UI
• Web Browser:
  • Google Chrome® 57 and above
  • Firefox® 52 and above
  • Safari® 11 and above
  • Microsoft® Edge 91 and above
• Cloud: Yes
• Security: Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication

4G

• Standard: LTE-TDD/LTE-FDD/WCDMA
• SIM Type: Nano SIM
• Category: 4
• Frequency:
  • LTE-FDD: B 1/3/5/7/8/20/28
  • LTE-TDD: B 38/40/41
  • WCDMA: B 1/5/8

Alarm and Event Management

• Smart Event:
  • Human & Vehicle Classification
  • Intrusion Detection
  • Line-Crossing Detection
  • Region Entering Detection
  • Region Exiting Detection
  • Object Abandoned Detection
  • Object Removal Detection
  • People Detection
  • Vehicle Detection
• Basic Event:
  • Motion Detection
  • Video Tampering Detection
  • Exception (Illegal Login)
• Alarm Linkage:
  • Memory Card Video Recording
  • Message Push
  • Audible Warning
  • White Light Flashing
• Linkage Method: N/A
• Output Notification: Message Push

Interfaces

• Network Interface: 1 RJ45 10/100M Self-Adaptive Ethernet Port
• Alarm: N/A
• Reset Button: Yes
• Power: DC Power Port
• On-board Storage: Built-In Memory Card Slot, Support MicroSD Card, Up to 256 GB
• Built-in Nano-SIM Card Slot: Yes
• Built-in Microphone: Yes; Records Anything Going on within a 15-ft Radius of the Camera
• Built-in Speaker: Yes
