Samsung WAD Series Interactive Display (Android OS)

SAMSUNG Interactive Display WAD Android OS

Display Specifications

• Diagonal Size: 65" / 75" / 86"
• Panel Type: ADS
• Resolution: 3,840 x 2,160
• Pixel Pitch (HxV): 372(H) x 372(V) / 429.6(H)×429.6(V)
• Brightness (Typical): 400 nits
• Contrast Ratio: 1,200:1
• Viewing Angle (H/V): 178°/178°
• Response Time: 8 ms
• Color Gamut: 72%
• Glass Haze: 25%

Frequency and Performance

• H-Scanning Frequency: 135 kHz
• Maximum Pixel Frequency: 78 MHz
• V-Scanning Frequency: 60 Hz
• Operation Time Support: 12/7 (12 hours a day, 7 days a week)

Connectivity

• HDMI In: 3 (Version 2)
• HDCP Version: 2.1
• USB Ports: 5 (1 x 2.0, 4 x 3.0)
• IR In: Yes
• Audio In: Stereo Mini Jack
• Audio Out: Stereo Mini Jack
• Video Out: Yes
• RS232 In/Out: Yes
• RJ45 In/Out: Yes
• WiFi: Yes
• Bluetooth®: Yes

Power

• Power Supply: AC 100-240V, 50/60Hz
• Power Consumption (On Mode): 385W
• Power Consumption (Sleep Mode): 0.5W or less

Dimensions and Weight

• 65" Set Dimensions (WxHxD): 1488 x 897 x 88 mm
• 75" Set Dimensions (WxHxD): 1709 x 1020 x 88 mm
• 86" Set Dimensions (WxHxD): 1957 x 1160 x 99 mm
• Package Dimensions (WxHxD): 1628 x 1024 x 208 mm
• Set Weight: 33.9 kg
• Package Weight: 42.9 kg

Operation Conditions

• Temperature Range: 0°C ~ 40°C
• Humidity Range: 10% ~ 90%

Mechanical Specifications

• VESA Mount: 600 x 400 mm
• Bezel Width:
  • 16.4mm (Upper)
  • 16.4mm (Left/Right)
  • 44.9mm (Bottom)
• Bezel Color: Space Gray
• Frame Material: Non-Glossy

Optional Features

• Touch Technology: IR format
• Operating System: Android 13
• SoC (System on Chip): Yes
• Flash Memory Size: 64GB

Unlimited learning possibilities

Introducing the Interactive Display WAD series, for engaging educational experiences. Based on Android OS, it provides a familiar and intuitive user experience. Download apps through Google Play and use pre-installed apps like YouTube and Chrome to stay productive and open a new era of education.

Effortless access to Google services

EDLA Certification

With an EDLA certification, the WAD series supports a variety of Google services like Google Play and YouTube. This access to major educational apps like Google Classroom leads to increased efficiency and enhanced communication with students.

Smart, wireless sharing on multiple devices

Powerful Screen Sharing

The WAD series supports screen mirroring for up to nine devices, increasing student engagement. This feature ensures every student is included and engaged as content can be shared on both the large display and individual devices. It can be used on iOS, Mac, Windows, Android, or Chrome OS.

Reduce eye strain with better eye care settings

TUV Certification

The WAD series is equipped with features to protect users' eye health. The anti-glare panel, low blue light, and flicker-free functions effectively block blue light and flicker while also diffusing reflection. The WAD series prevents glare even in bright settings.

Seamless learning in various environments

Superior Durability

The WAD series protects against electrical surges³ by using a ceramic fuse and 500V (DC) capacitor that absorbs instant spikes in voltage. It is also a valuable tool for schools in high humidity or rainy climates with anti-humidity glue applied to the critical areas of the chipset.
