X3100i | 4K HDR 4LED Flagship Console Gaming Projector

Display Specifications

• Brightness (ANSI lumens): 3300
• Resolution: 4K UHD (3840×2160)
• Native Aspect Ratio: 16:9
• Contrast Ratio (FOFO): 600,000:1 (with Lightsource Dimming)
• Display Color: 30-bit (1.07 billion colors)
• Light Source: 4LED
• Light Source Life:
  • Normal: 20000 hrs
  • ECO: 30000 hrs
  • SmartEco: 30000 hrs

Optical Specifications

• Throw Ratio: 1.15 ~ 1.50
• Zoom Ratio: 1.3x
• Lens: F/# = 1.8 - 2.25 mm, f = 17.02 - 22.21 mm
• Projection Offset (Full-Height): 110%
• Keystone Adjustment: 2D, (Auto) Vertical ± 30 degrees; Horizontal ± 30 degrees
• Lens Shift Vertical: 40%~60%

Picture Specifications

• DCI-P3 Coverage: 100%
• Rec. 709 Coverage: 95%
• Picture Modes: 3D, Bright, Cinema, FPS, HDR FPS, HDR RCG, HDR RPG, HDR SPG, HDR10, RCG, RPG, SPG, User

Compatibility

• Input Lag:
  • 16.7 ms (1080P 60Hz)
  • 16.7 ms (2K 60Hz) *downscaling to 1080p 60Hz
  • 16.7 ms (4K 60Hz)
  • 4.2 ms (1080P 240Hz)
  • 8.3 ms (1080P 120Hz)
  • 8.3 ms (2K 120Hz) *downscaling to 1080p 120Hz
• Resolution Support: VGA (640 x 480) to 4K UHD (3840 x 2160)
• Horizontal Frequency: 15K~135KHz
• Vertical Scan Rate: 23~240Hz

I/O Interface

• HDMI in:
  • HDMI-1 (2.0b/HDCP2.2)
  • HDMI-2 (2.0b/HDCP2.2)
• USB Type A: (x1), USB Type A(2.0/Reader/FW Upgrade)
• RS232 in (DB-9pin): (x1)
• DC 12V Trigger (3.5mm Jack): (x1)

Audio

• Speaker: (x2), 5W Chamber
• Audio out (3.5mm Mini Jack): (x1)
• HDMI Audio Return: Yes, eARC, Dolby Atmos
• S/PDIF: Multi-Channel, RAW

Environment

• Operating Temperature: 0~40℃
• Power Supply: AC 100 to 240 V, 50/60 Hz
• Typical Power Consumption (110V): 330W
• Stand-by Power Consumption: <0.5W
• Acoustic Noise (Typ./Eco.)(dB): 32/28 dBA

Accessories

• Android TV dongle: QS02
• Remote Control w/ Battery: RCI074
• Power Cord (by region): x1 (1.8M)
• Quick Start Guide: (x1) 1L
• Warranty Card (by region): Yes
• Universal Ceiling Mount: CM00G3, (Optional)

Dimension & Weight

• Dimensions (WxHxD) (mm): 272 x 213 x 259
• Net Weight (kg): 6.8
• Dimensions (WxHxD) (inch): 10.7 x 8.4 x 10.2
• Net Weight (lb): 15.0

Projection System

• Projection System Format: DLP

Spatial Audio for Precision Gaming

Sense every in-game shift through pinpoint sound placement, from explosive blasts to tranquil moments.

Build Your Sanctuary

Step into a world of gaming luxury provided by the X3100i gaming projector. Boasting 3300 ANSI lumen high brightness and versatile installation capabilities, the X3100i is designed to help you craft your ultimate gaming haven.

Learn How to Mount a X3100i Gaming Projector on Your Ceiling

Vertical Lens Shift

Support for 40-60% vertical lens shift delivers more installation flexibility, either for mounting on a ceiling or placing the projector on a table. Images can be shifted up and down without sacrificing image quality.

Easy, Flexible Projection

With a throw ratio of 1.15-1.5 and 1.3x zoom, you can customize screen sizes to fit various spaces effortlessly and project a captivating 100” screen from just 2.5m for expansive entertainment viewing. All without the hassles of complicated installation.

Digital Zoom

Embrace a wider view and effortlessly resize the projected image thanks to digital zoom. All-encompassing gaming is now showing right in front of you without any blind spots or view-compromised angles.

*Note: digital zoom may impact input lag.

Tailored for Every Game Type

Customized visual and audio tuning for different game genres delivers better gaming experiences and enhanced sensory immersion.

Auto Game Mode for All Consoles

BenQ's Auto Game Mode effortlessly identifies Xbox, PlayStation, and Switch console inputs, instantly recalling your previous game mode settings for a tailor-made gaming experience.

Precision Enhanced with FPS Crosshair

The FPS Crosshair feature projects a targeting reticle onto the screen, empowering players to swiftly and accurately lock onto adversaries in ever-challenging battles.

BenQ SettingXchange

Download expert projector image settings for top games and experience gameplay through the eyes of pros thanks to ready-made celebrity profiles. Share your projector image settings with fellow gamers to help them level their experiences, or import theirs. Experiment and find your best profile with this intuitive utility

Game Bigger and Brighter

Enjoy superior 4LED color volume, high contrast, optimized saturation, and enduring colors with long 10+ year LED light source life.
