Hikvision 4 MP Smart Bullet Network Camera | DS-2CD1043G2-LIU
Hikvision 4 MP Smart Bullet Network Camera | DS-2CD1043G2-LIU
Hikvision 4 MP Smart Bullet Network Camera | DS-2CD1043G2-LIU

    Hikvision 4 MP Smart Bullet Network Camera | DS-2CD1043G2-LIU

    $119.40
    Tax included. Shipping calculated at checkout.

    Specification

    Camera

    • Image Sensor: 1/3" Progressive Scan CMOS
    • Max. Resolution: 2560 × 1440
    • Shutter Time: 1/3 s to 1/100,000 s
    • Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR
    • Day & Night: IR cut filter
    • Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

    Lens

    • Lens Type: Fixed focal lens, 2.8 and 4 mm optional
    • Lens Mount: M12
    • Iris Type: Fixed
    • Aperture: F1.6

    DORI

    • 2.8 mm: D: 63 m, O: 25 m, R: 12 m, I: 6 m
    • 4 mm: D: 78 m, O: 31 m, R: 15 m, I: 7 m

    Illuminator

    • Supplement Light Type: IR, White Light
    • Supplement Light Range: Up to 30 m
    • Smart Supplement Light: Yes
    • IR Wavelength: 850 nm

    Video

    • Main Stream:
      • 50 Hz: 20 fps (2560 × 1440), 25 fps (1920 × 1080, 1280 × 720)
      • 60 Hz: 20 fps (2560 × 1440), 24 fps (1920 × 1080, 1280 × 720)
    • Sub-Stream:
      • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
      • 60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
    • Video Compression:
      • Main stream: H.265+/H.265/H.264+/H.264
      • Sub-stream: H.265/H.264/MJPEG
    • Video Bit Rate: 32 Kbps to 8 Mbps
    • H.264 Type: Baseline Profile, Main Profile, High Profile
    • H.265 Type: Main Profile
    • Bit Rate Control: CBR, VBR
    • Region of Interest (ROI): 1 fixed region for main stream

    Audio

    • Audio Type: Mono sound
    • Environment Noise Filtering: Yes
    • Audio Sampling Rate: 8 kHz/16 kHz
    • Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
    • Audio Bit Rate: 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)

    Network

    • Security: Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
    • Simultaneous Live View: Up to 6 channels
    • API: Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)), ISAPI, SDK
    • Protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
    • User/Host: Up to 32 users, 3 user levels: administrator, operator, and user
    • Client: iVMS-4200, Hik-Connect
    • Web Browser: Plug-in required live view: IE 10, IE 11, Local service: Chrome 57.0+, Firefox 52.0+


    • Wide Dynamic Range (WDR): 120 dB
    • SNR: ≥ 52 dB
    • Day/Night Switch: Day, Night, Auto, Schedule
    • Image Enhancement: BLC, HLC, 3D DNR
    • Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser
    • Privacy Mask: 4 programmable polygon privacy masks

    Interface

    • Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
    • On-Board Storage: -F: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
    • Built-in Microphone: Yes
    • Reset Key: -F: Yes

    Event

    • Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception
    • Linkage: Upload to FTP/memory card (-F), send email, notify surveillance center, trigger recording (-F), trigger capture

    General

    • Power: 12 VDC ± 25%, 0.4 A, max. 5 W, Ø 5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max. 6.5 W
    • Material: Metal & Plastic
    • Dimension: 170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7")
    • Package Dimension: 216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
    • Weight: Approx. 270 g (0.6 lb.), With Package Weight: Approx. 481 g (1.1 lb.)
    • Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
    • Startup and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
    • Language: English, Ukrainian
    • General Function: Heartbeat, anti-banding, mirror, password protection, password reset via email

    Approval

    • EMC: FCC: 47 CFR Part 15, Subpart B, CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014, RCM: AS/NZS CISPR 32: 2015, IC: ICES-003: Issue 7
    • Safety: UL: UL 62368-1, CB: IEC 62368-1: 2014+A11, CE-LVD: EN 62368-1: 2014/A11: 2017, BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
    • Environment: CE
    • -RoHS: 2011/65/EU, WEEE: 2012/19/EU, Reach: Regulation (EC) No 1907/2006
    • Protection: IP67: IEC 60529-2013



      4 MP Smart Hybrid Light Fixed Bullet Network Camera | DS-2CD1043G2-LIU
