| Specification | HUAWEI IdeaHub Board 2 65-inch | HUAWEI IdeaHub Board 2 86-inch |
|---|---|---|
| Product Information | ||
| Model | IHB2-65SU | IHB2-86SU |
| Device Size | 65-inch | 86-inch |
| Included Stylus Pens | 2 | 2 |
| Stylus Design | PET pen tip / anti-skid pen body / magnetic attachment | PET pen tip / anti-skid pen body / magnetic attachment |
| Power Cable | 1 | 1 |
| OPS | Optional (i5/i7) | Optional (i5/i7) |
| Rolling Stand | Optional (VESA-standard interface) | Optional (VESA-standard interface) |
| Wall Mount Bracket | Optional (VESA-standard interface) | Optional (VESA-standard interface) |
| IdeaHub Controller | Optional | Optional |
| Screen | ||
| Resolution | 4K UHD (3840 x 2160) | 4K UHD (3840 x 2160) |
| Viewing Angle | 178° | 178° |
| Glass Hardness | ≥ 7H | ≥ 7H |
| Screen Lamination | Zero-gap bonding | Zero-gap bonding |
| Color Depth | 10-bit (8-bit + FRC) | 10-bit (8-bit + FRC) |
| Backlight Type | D-LED | D-LED |
| Number of Touch Points | 20 | 20 |
| Screen Refresh Rate | 60 Hz | 60 Hz |
| Aspect Ratio | 16:9 | 16:9 |
| Eye Protection | ||
| Optical Anti-Blue Light | Yes | Yes |
| Anti-glare / Glare Prevention | Yes | Yes |
| Adaptive Brightness | Yes | Yes |
| TĂśV Rheinland Low Blue Light Certification | Yes | Yes |
| TĂśV Rheinland Eye Comfort Certification | Yes | Yes |
| Writing | ||
| Writing Latency | 25 ms | 25 ms |
| Precision | ±1 mm | ±1 mm |
| Whiteboard Saving Mode | QR code scanning / Email / Local disk / USB flash drive | QR code scanning / Email / Local disk / USB flash drive |
| Intelligent Writing | Yes | Yes |
| Projection & Collaboration | ||
| Projection Modes | IdeaShare App; IdeaShare Key; mobile drop-down menu; HDMI; Type-C wired projection | IdeaShare App; IdeaShare Key; mobile drop-down menu; HDMI; Type-C wired projection |
| Wireless Projection Performance | Up to 4K30 | Up to 4K30 |
| Wired Projection Performance | 4K60 | 4K60 |
| Supported OS for Projection | Android / Windows / iOS / macOS | Android / Windows / iOS / macOS |
| Annotate During Projection | Yes | Yes |
| Reverse Control | Yes | Yes |
| Wi-Fi | ||
| Dual-Wi-Fi Module | Yes | Yes |
| Wi-Fi Frequency | 2.4 GHz / 5 GHz | 2.4 GHz / 5 GHz |
| Audio | ||
| Frequency Domain | 100 Hz–20 kHz | 100 Hz–20 kHz |
| Speaker Unit | 2 x full frequency speaker + 2 x high frequency speaker | 2 x full frequency speaker + 2 x high frequency speaker |
| Stereo | Yes | Yes |
| System | ||
| CPU | 4-core | 4-core |
| RAM | 4 GB | 4 GB |
| Flash | 32 GB | 32 GB |
| Operating System | Android 9.0 / Windows 10 (OPS required for Windows) | Android 9.0 / Windows 10 (OPS required for Windows) |
| Terminal Interface | ||
| Front USB Type-C | 1 | 1 |
| Front USB Type-A | 2 | 2 |
| Rear USB Type-A | 1 | 1 |
| Rear USB Type-B | 1 (reverse control) | 1 (reverse control) |
| HDMI Input | 2 | 2 |
| HDMI Output | 1 | 1 |
| COM Port | 1 | 1 |
| RJ45 Network Port | 1 | 1 |
| 80-pin OPS Port | 1 | 1 |
| 3.5 mm Line-in | 1 | 1 |
| 3.5 mm Line-out | 1 | 1 |
| Dimensions & Weight | ||
| Product Dimensions (H x W x D) | 892.5 x 1484.5 x 91.6 mm | 1157.0 x 1953.0 x 91.8 mm |
| Package Dimensions (H x W x D) | 1050 x 1650 x 220 mm | 1300 x 2090 x 250 mm |
| Net Weight | 35.0 kg | 62.0 kg |
| Gross Weight | 42.5 kg | 73.5 kg |
| Warranty | |
|---|---|
| Warranty Period | 1 Year |
